- Durable & Sturdy: The aluminum engine shell, iron fuel tank with baking paint, a 415# steel chain with shot blasting process, achieving a max bearing capacity of 440 pounds and ensuring superior performance and a longer lifespan.
- Strong Power: The engine boasts a robust 3.5HP horsepower, a displacement of 100cc, a rated power of 2kw/h, and a max rotating speed of 3600RPM, which provides you with strong power and accelerates your bike to a max speed of 50km/h.
- Large Fuel Tank: The bike motor kit measures 11.81x5.51x5.9 inches with a large capacity of 0.52 gallons, allowing bicycle engine kit to work for a long time.
- Low Fuel Consumption: The overhead valve is used, which effectively helps reduce carbon buildup and dramatically improves fuel savings.
- Quiet Operation: This bicycle engine kit only has slight noise (about 75dB) and vibration when used.
Details
Convenient Handle: The ergonomic T-shaped start handle provides a point of application of force for easy and comfortable starting.
Chain Cover: It's made of high-quality iron and can protect you from getting hurt.
Pulling Rope: The pulling rope is made of nylon, which is more wear-resistant and durable.
Specifications
Color: Black, Silver
Type: Single Cylinder, 4-stroke, Air-cooling
Material: Aluminum, Iron, #415 Steel, Rubber, Nylon
Assembly Required: Yes
Starter System: Hand Start
Number of Teeth: 44
Ignition Mode: Electronic Ignition
Max Torque: 4.5N-m
Bore Stroke: 56x40mm/2.2x1.57inch
Displacement: 100CC
Horsepower: 3.5HP
Rated Power: 2kw/h
Max Rotating Speed: 3600rpm
Max Speed: 50km/31miles/h
Compression Ratio: 7:1
Fuel Tank Capacity: 2L/0.52 Gallons
Fuel Consumption: 2.5L/0.66 Gallons/100KM
Lubricant Capacity: 0.4L/0.1 Gallons
Gasoline Type: 92#, 95#
Max Load Bearing Capacity: 200kg/440lbs
Noise: About 75 decibels
Gross Weight: 21.65kg/47.73lbs
Net Weight: 19.2kg/42.32lbs
Chain Cover Size: 41x7.5cm/16.14x2.95in
Fuel Tank Size: 30x14x15cm/11.81x5.51x5.9in
Gear Diameter: 18cm/7.08in
Diameter of Bicycle Teeth Disc: 18cm/7.08in
Engine Size: 36x28x23cm/14.17x11.02x9.05in
Package Size: 71x35x28.5cm/27.95x13.77x11.22in
Package Included
1xBicycle Engine Kit
1xEnglish Manual
All Accessories for Assembly
Notes
1. Please carefully read the manual and strictly follow the precautions to have a better experience.
2. Please note that professional installation is recommended.
3. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
